Airport Caster

Model No.: CP24-AC-3

Product name: Orange Plastic wheel Air Cargo Casters

Optional Wheel:Nylon Wheel

Loading capacity: 227 KGS

Housing:Made of pressed steel, zinc plated, swivel head ball bearing and wheel double ball bearings

Material：PP

Bearing Type:ball Bearing

Temperature range:-30℃~80℃

1 Customers who purchase casters in our company can enjoy free maintenance for 1-3 years

2 Our company guarantees 7 * 16 hours of service

3 Samples delivery in 7 days, for special case of OEM, 15 days to finalize the project.



Specification：

Type	PP Casters For air cargo transportation
Wheel size(mm)	Wheel Diameter: 70mm   Wheel width: 35mm
Tread Material	Polypropylene
Plate Diameter(mm)	112.5mm
Bolt Hole Pattern(mm)	87.5mm
Mounting Height(mm)	102mm
Thickness(mm)	Top plate: 3.5mm Housing:3 mm
Surface Treatment	3rd Grade Environmental Yellow Zinc Horn
Tread Color	Orange
Applicable Temperature	-30℃~80℃
Load Capacity(kgs)	227kgs
Bearing Type	Swivel Bearing:precision Ball bearings  wheel bearing:precision Ball bearings





Advantages:

1-Strict testing to secure the quality

2-Competitive Price discount for 15%-25% compared to other suppliers

3-We use the Trivalent Zinc plating and imported material to be invironmental protection

4-100% quality inspection

5-Stable and swivel head to be 15% longer service life

6-European and American Specifications and standards compatible

7-We are one of the three high cost performance air cargo caster manufacturer





Model	Wheel Dia.*Width (mm)	Total Height (mm)	Offset (mm)	Top Plate Dia.(mm)	Hole Pattern(mm)	Hole Size (mm)	Load Capacity (kgs)
CP24-AC-3	70*35	102	23.5	112.5*3.5	87.5*3.5	8.8	227



Customer satisfaction:





Production and packing

Application



Delivery & Payment Term:

The important feature of modern material handling is that the material handling and processing, assembly, packaging, inspection and other related processes and sites are considered and arranged as a whole logistics system. In the whole logistics process of mechanical factory, there are extensive and heavy material handling operations, forming a more complex in plant logistics system than other industries. It is not only an important part of production, but also an indispensable source of information for enterprise management. Mastering the logistics information can timely understand the variety, quantity, quality, location, production progress, capital turnover and other dynamic and existing problems of raw materials, parts and products, which helps to improve enterprise management and improve economic benefits.

The off-site material handling of mechanical factory is closely related to site selection and professional cooperation. Material handling outside the plant usually includes road transportation, railway transportation, waterway transportation and so on. Each factory chooses transportation mode according to external transportation, raw material supply, specialized cooperation and product sales. The railway transportation directly to the factory needs to build a special line and provide its own railway vehicles, which is often large investment and covers a lot of land. When water transportation is adopted, it is necessary to consider such factors as the nature and source of materials, the characteristics and destination of products, the loading and unloading capacity of the wharf, as well as infrastructure investment and land and water transfer costs.

Highway transportation is the most widely used material handling outside the factory, and the vehicle can reach the storage and use place of materials directly. Automobile transportation should pay attention to saving energy, improving loading and unloading conditions, increasing vehicle utilization and full load coefficient, and reducing transportation cost. In modern enterprise management, factories adopting just in time (JIT) system transport the purchased raw materials and parts directly to the working place of the factory on time, so as to cancel the intermediate storage and reduce multiple handling, which can significantly shorten the production cycle and save the working capital.
