Leveling Casters For Pool Tables
video

Leveling Casters For Pool Tables

Model# GD100S
Certs: ISO9001:2015, ROHS and REACH205 Compliant, Emvironmental friendly protection testing
Application:machines, automations, stands, medical equipment, lab equipment, airconditioning containers, pool tables, home and office furnitures, mould machines, precision apparatus, computer racks, tool cabinets, wholesale containers, work stations, contifuge , testing chamber, workbench and many other areas.
Product Introduction

Model No.: CP82-GD 100S



Overview:


We hotly introduce the most suitable Leveling Casters for Pool Tables for you, because of the stableness and height adjustability functions.

There are all kinds of locking casters on the net. As long as you do a Google search, many types will appear. The problem is that there is no good way to attach leveling pads to casters. All you can do is make a rectangular frame out of 2 inches x 6 inches of wood. Locking casters shall be installed at every corner under the leveling pad. The difficult part may be lifting the billiard table to the mobile rack. Once this is done, the table will need to be flat in the exact position, and it will always be played.It has to flatten out in the right place when you push it away and then bring it back into the play area. You may want to mark the floor in these 4 places. Now, the only thing you may not like about this arrangement is the new height of the pool table. It may be 4 "-6" taller than before. Of course, when you don't know how to choose casters, there is a caster, which is multifunctional and just comes in handy. It is Leveling Casters for Pool Tables.


Taking a step back, if the two Leveling Casters for Pool Tables take up 4 wheels load capacity, the loading wheels can bear much weight to the two wheels. If you use the NBR pad to bear the weight that will be much better, and the pool tables can be moved indoor and outdoor without any fake energy wasted.


We think they are the currently most suitable items which you can install and unistall conveniently.








Specification

Type

testing equipment casters

Wheel size(mm)

75*30

Tread Material

MC Nylon

Mounting Height(mm)

120

Plate Thickness(mm)

4-8.5

Surface Treatment

Baseboard:carbon steel/stainless steel

Adjust:M C Nylon

Housing:Aluminium alloy

Base:Aluminium alloy

Foot: NBR/M C Nylon

Tread Color

Black/blue

Applicable Temperature

-15℃~70℃

Load Capacity(kgs)

750

Bearing Type

Sliding bearings


CP82GD-S Series

image003image013

Model

Wheel dia(mm)

Tread width(mm)

Mount height(mm)

Top-plate

Stem Length(mm)

Stem Dia.(mm)

Adjust ground height(mm)

Single wheel load(mm)

4 wheel load(KGS)

CP82GD-40S

42

20

71

Octagon

10

M8

10

50

100

CP82GD-60S

50

25

82

Octagon

15

M12

10

250

500

CP82GD-80S

63

30

103

Octagon

15

M12

15

500

1000

CP82GD-100S

75

30

120

Octagon

20

M16

12

750

1500

CP82GD-120S

75

30

120

Octagon

20

M16

12

1000

2000








GD100s foot casters

GD100s foot masters



leveling casters structures


Ratchet Casters

foot operated casters

nylon based foot leveling casters

self adjust leveling casters

aluminum leveling casters

250kgs leveling casters

750 kgs height adjustable casters

500kgs leveling casters

1000kgs leveling casters


Testing and Certificate



(1) Lelveing Caster REACH205 COMPLIANT TESTING REPORTS by Europe and North America Authority Approved, Environment friendly compatible when being applied for wholesales, distribution and terminal application.

REACH205 COMPLIANT TESTING REPORT (2)REACH205 COMPLIANT TESTING REPORTREACH205 COMPLIANT TESTING REPORT (3)



(2) Lelveing Caster ROHS TESTING REPORTS by Europe and North America Authority Approved

ROHS TESTING REPORTROHS TESTING REPORT (2)
