Air cargo casters for decks

Model No.: CP24-2
Product name: Nylon Airport Cargo Casters
Optional Wheel:NA

Loading capacity: 250KGS
Housing:zinc plated, yellow Passivated Coating

Wheel: ...





Overview:

Air cargo casters are designed for reverse applications, such as air cargo units. Specially designed top plate and dust cover make this industry's perfect caster. High quality nylon wheel design can withstand strong impact, and ball bearing can roll smoothly in the worst environment.



Application:

Our casters are popularly used in the airport cargo caster decks, cargo transportation platform.



Features & Advantages:

1 Abrasion resistant

2 Shock resistant

3 Sealed Swivel Bearing

4 Rounded Metal guards to prevent debris from entering bearing



After sales service：

1 Customers who purchase casters in our company can enjoy free maintenance for 1-3 years

2 Our company guarantees 7 * 16 hours of service

3 Samples delivery in 7 days, for special case of OEM, 15 days to finalize the project.



Specification：

Type	Airport Cargo Casters
Wheel size(mm)	58*35
Tread Material	Nylon
Mounting Height(mm)	96
Plate Thickness(mm)	3
Surface Treatment	Zinc Plated and yellow Passivated Coating
Tread Color	White
Applicable Temperature	-30℃~80℃
Load Capacity(kgs)	250
Bearing Type	Ball bearings



Advantages:

1-Strict testing to secure the quality

2-Competitive Price discount for 15%-25% compared to other suppliers

3-We use the Trivalent Zinc plating and imported material to be invironmental protection

4-100% quality inspection

5-Stable and swivel head to be 15% longer service life

6-European and American Specifications and standards compatible

7-We are one of the three high cost performance air cargo caster manufacturer



Swivel

CP24-AC-2

Model	Wheel Dia.*Width (mm)	Total Height (mm)	Swivel Radius (mm)	Top Plate (L*W)	Hole Spacing (mm)	Hole Size (mm)	Bearing Type	Load Capacity (KG)
CP24-AC58.35-2	58*34	96	25	111*80*3	86*61	4/2	Ball bearing	250
CP24-AC70.35-2	70*34	102	25	111*80*3	86*61	4/2	Ball bearing	250



Production and packing



Customer satisfaction:



High Grade Material：



Ready for shipment：



Delivery & Payment Term:
